Significance of viscosity index in lubricants
Technical Concept: Viscosity Index
To begin with, it is important to select the right lubricant in order to protect your machinery. This depends largely on the viscosity index of the fluid.
So, let’s learn more about Viscosity Index & its significance.
Frequently Asked Questions- Viscosity Index
For improving viscosity index of the base oils, some polymer additives are added to the oils to form multi-grade viscosity oils. These modifiers are temperature sensitive and contract at low temperatures.
The greater the viscosity index, the smaller the change in fluid viscosity for the given temperature change and vice versa, thus a fluid with a low viscosity index will experiece a relatively , large swing in viscosity as the temperature changes.
Viscosity is a property which tends to decrease as the temperature increases.Viscosity index indicate the resistance of an oil to the changes in viscosity with temperature. smaller the change in viscosity with temperature, higher is the viscosity index of the oil.
Dynamic Viscosity is defined as fluid’s resistance to deform when subjected to a force. Unit of Dynamic Viscosity is Centipoise (cP), Where, 1 cP = mPa.s
Viscosity Index improvers are added to produce high quality Lubricants.These are generally polymer additives that reduce the impact of increasing temperature on viscosity of Lubricants.
Viscosity modifiers are used in multigrade engine oils,gear oils,automatic transmissions,etc. Mostly these are used in automobile sectors where vehicles are subjected to tremendous temperature swings.
The Viscosity Index Improvers are most commonly used in gear oils,multigrade engine oils,power steering fluids,Hydraulic fluids,Automatic transmission fluids,etc.They flow more freely at low temperature so it can reach the bearings quicker.
Viscosity of lubricant can be considered an important feature. The higher the viscosity, the higher the friction between the oil and the shaft is, but Hydrodynamic film is thicker.Friction generates heat, which reduces the viscosity, and the thickness of the film may result in metal to metal contact.
What is Viscosity?
Prior to understanding the viscosity index, we need to comprehend the physical property of fluids called “Viscosity”.
Here the question arises, What is Viscosity? Generally, Viscosity is the most important property for the lubricant and it can be defined as an oil’s resistance to flow and shear.
Taking a proactive approach to monitoring your lubricant’s viscosity can have a major effect on the health, and life of your machinery.
What is the Viscosity index? How does it relate to Viscosity?
Viscosity Index (VI) is defined as the rate of change of viscosity with respect to temperature. This means viscosity is also influenced by temperature.
Particularly, the quality and formulation of a lubricant will impact how much its viscosity will drop with an increase in temperature.
So, it is important to study the VI to anticipate whether the lubricant being referred to, meets the asset’s requirements based on the operating temperature range.
Determination of the Viscosity Index
Generally, there are two standard procedures to calculate the viscosity index:
ASTM D22706 and ISO 29097.
The viscosity is measured at two temperatures i.e. 40 degrees C and 100 degrees C to determine an oil’s VI. This is then compared to a scale based on two reference oils.
The viscosity index of conventional mineral oil is well known and is between 95 to 100 because the VI has no units of measure.
The VI of highly refined mineral oils is approximately 120.
Whereas, the synthetics may have a VI of nearly 250.
Here, the higher number indicates that the lubricant changes its viscosity at a lower rate based on the temperature.
A higher VI is more captivating on the grounds, as a result, it enables the lubricant to provide a more stable lubricating film over a wider temperature range.
Remember, a slight difference in temperature can result in a huge viscosity change that could be unfavorable to the asset!
With a changing temperature, a low VI represents a major change in the viscosity of a lubricant. Such lubricants are highly viscous at low temperatures and thin at high temperatures.
It is completely the opposite in the case of high VI. Here, there is a small change of viscosity over a wide temperature range.
Viscosity index is the most important parameter in demonstrating the lubricant’s temperature-related flow properties. There are plenty of Industrial Lubricants options in the market, but it is always a good idea to check the specifications of the lubricant manufacturer to give a proper lubricant solution.
With a proper solution and accurate viscosity index, one can surely achieve maximum life expectancy and reliable operation of the machinery.
